ENGINE | |
Emission Standard | Euro 5,EPA4 |
Make /Model | KUBOTA /D1703 |
Power /Rotation speed | 18.5kw(25HP)@2200rpm |
Number of cylinder | 3 |
Type | In-line,water cooled, 4-stroke ,mechanical pump, normally aspirated |
Max.torque | 97.4N.m/1500rpm |
Displacement | 1.642L |
TRACK DRIVING SYSTEM | |
Maximum Travel speed(High/low) | 4.4/2.4km/h |
Width of steel track shoe | 300mm |
Carrier roller(Each side) | 1 |
Supporting roller(Each side) | 4 |
PERFORMANCE PARAMETER | |
Standard Bucket capacity | 0.12m³ |
Swing speed | 12rpm |
Maximum Grade ability | 58%(30°) |
Ground pressure | 32Kpa |
Maximum Bucket digging force | 30.4KN |
Maximum Arm digging force | 18.2KN |
Hydraulic system pressure | 22.5Mpa |
Machine weight | 3810kg |
Boom length | 2535mm |
Arm length | 1400mm |
Fuel tank capacity | 40L |
Hydraulic oil tank capacity | 44L |
Engine oil capacity | 7L |
Radiator capacity | 3.8L |
Final drive | 2*0.7L |
MACHINE SIZE | |
Overall dimension (L*W*H) | 4915mm*1720mm*2525mm |
Axle base(Track length on ground) | 1670mm |
Length of rubber track | 2154mm |
Track gauge | 1420mm |
Minimum Ground clearance | 295mm |
Swing radius at tail | 860mm |
Swing radius at front | 2538mm |
Height of blade | 350mm |
WORKING RANGE | |
Maximum Digging height | 4800mm |
Maximum Dumping height | 3406mm |
Maximum Digging depth | 3208mm |
Maximum Vertical digging depth | 2957mm |
Maximum Digging distance(working radius) | 5480mm |
Maximum digging distance (on ground) | 5359mm |
Minimum swing radius | 2530mm |
Max.height when min.swing radius | 3655mm |
Maximum Lifting height of blade | 365mm |
Maximum Cutting depth of blade | 385mm |
Boom swing angle(Left/Right) | 55°/65° |
