| YT150 CRAWLER EXCAVATOR | ||
| PUMP | Kawasaki | |
| Valve | KYB | |
| RATED POWER | kW(HP) / rpm | 71(97)/2200 |
| BUCKET CAPACITY | m3 | 0.53-0.58 |
| ENGINE | - | Cummins |
| WORKING WEIGHT | kg | 14100 |
| WALKING SPEED (1 SPEED / 2 SPEED) | km / hr | 5.04/3.01 |
| SWING TORQUE | kgf▪m | 3655 |
| MAXIMUM DIGGING HEIGHT | mm | 8750 |
| MAXIMUM DIGGING DEPTH | mm | 5092 |
| MAXIMUM VERTICAL DIGGING DEPTH | mm | 4650 |
| MAXIMUM EXCAVATION RADIUS | mm | 8305 |
| FULL LENGTH | mm | 7662 |
| FULL WIDTH | mm | 2600 |
| FULL HEIGHT (TO THE TOP OF THE BOOM) | mm | 2476 |
| FULL HEIGHT (TO THE TOP OF THE CAB) | mm | 2773 |
