Solid and Reliable DesignThe integral frame adopted features compact structure and high firmness and reliability. All critical structural parts are optimized through finite element analysis to realizereasonable stress distribution.The international first-class quality hydraulic units adopted feature high reliability, energy-saving, and high efficiency.Flexible OperationsCompact structure, low turning radius, and strong site adaptability.The quick-change coupling equipped can change attachments rapidly in the construction site.The bucket can automatically maintain level status during lifting to prevent scattering of material and improve working efficiency.Incomparable Multi-FunctionalitiesThe international interchangeable quick-change coupling enables the change of tens of attachments, including sweeper, planer, breaking hammer, and ditcher, rapidly and conveniently.Safe and Comfortable Operating EnvironmentThe ROPS&FOPS cab and the seat belt, bumper, fire extinguisher, and safety hammer equipped guarantee the personal safety of the operator. The cab features large space, adjustable seats, and com fortable operations.The joysticks and the instrument panel are arranged in accordance with ergonomic principles so that the driver can always maintain the best comfort to make operations easier.The standard double-accelerator control model can use the pedal accelerator or work at preset constant power to save the operation labor.Convenient MaintenancesThe cab can be tilted backward for a large angle to make the repair and maintenance portions more accessible.The rear hood and upper hood can be opened conveniently and all units and pipelines are easily accessible to save the repair and maintenance labor and time.
| JC45G |
整机性能Specifications |
|
额定载荷Rated operating capacity(kg) | 700 |
倾翻载荷Tipping load(kg) | 1400 |
铲斗容量Bucket capacity(m3) | 0.4-0.5 |
机器操纵质量Operationg weight(kg) | 2800 |
行驶速度Max. travel speed(km/h) | 12 |
工作流量Hydraulic pump flow(L/min) | 75 |
油箱容量Fuel tank capacity(L) | 70 |
轮胎型号Tires | 10/16.5NHS |
整车尺寸Overall dimensions(mm) | 3350×1720×2050 |
整机参数Dimensions |
|
最大操作高度Height at maximum extension(mm) | 3980 |
铰接销高度Height to bucket hinge pin(mm) | 3080 |
带斗宽度Width with bucket(mm) | 1730 |
轮距Track width(mm) | 1450 |
轴距Wheelbase(mm) | 991 |
离地高度Ground clearance(mm) | 180 |
倾倒角Dump angle | 30° |
倾倒高度Dumping height(mm) | 2380 |
接近角Rollback at ground | 26° |
离去角Angle of departure | 20° |
发动机Engine |
|
型号Maker/Model | 490 |
功率转速Net power | 50hp/2500rpm |
类型Type 直喷直列水冷四冲程柴油机 | 4 Cylinder in-line, Water cooled, 4 stroke, Diesel engine |
排量Displacement(L) | 2.7 |
标准配置Standard |
|
开式驾驶室Open-type operator cab |
|
手动控制Hand control system(Mechanical type) |
|
标准铲斗Standard bucket |
|
辅具输出装置Auxiliary hydraulic couplers |
|
可选配置Optional |
|
低温起动装置 | Prehest starting assist system for extreme cold weather |
内置暖风 | Cab fitted with a heater as standard |
冷暖空调 | Air conditioner |
双速系统 | 2-speed transmission system |
辅具Attachments： 挖掘机、破碎锤、推土板、钻孔机、清扫机、叉铲、开沟机、抓木叉、组合铲等 | Backhoe,Breaker,Angle blade,Auger,Sweeper,Pallet fork,Combinition bucket,Mower,Asphalt cutter,and More |
