YT388D Specifications | |||
1 | Total length(bucket at ground) | 6450±80mm | |
2 | Total width | 2350±20mm | |
3 | Bucket width | 2620mm | |
4 | Total height (cabin top) | 3120±10mm | |
5 | Total height (digging boom top) | 3940 ±20mm | |
6 | Wheel base | 2335±10 mm | |
7 | Wheel tread | 2139 ±10mm | |
Specs of loader | |||
1 | Rated load | 2800KG | |
2 | Operating weight | 9300kg | |
3 | Rated bucket capacity | 1.4m³ | |
4 | Max. Dumping height (41o dumping angle) | 2850±50 mm | |
5 | Dumping distance | 870±20 mm | |
6 | Turning radius(Tires outside) | 5750±50mm | |
Specs of excavator | |||
1 | Rated digging bucket capacity | 0.4m³ | |
2 | Max. Digging depth | 3820±20 mm | |
3 | Max. Digging radius | 5345±20mm | |
4 | Max. Loading height | 3740±20mm | |
5 | Max. Digging force | 5100kgf | |
6 | Max.Digging height | 5470 ±20mm | |
7 | Lifting force at Max. Digging radius | 1220kg | |
Engine | |||
1 | Engine model | Yuchai | |
2 | Cooling type | Water cooling | |
3 | Rated power | 85(kW) | |
5 | Rated speed | 2200(r/min) | |
6 | Max. Torque | 400(N.M) | |
Transmission | |||
1
| Hydraulic torque convertor
| Model | 290 |
Cooling way | Pressured oil circle | ||
2 | Gearbox
| Model | 15 |
Type | Mechanically Operated Hydraulic Synchronized Shift | ||
3 | Driving axles | Model | WZL100 |
4 | Gear shift | Forward 4 Backward 4 | |
5 | Speed（F/R）km/h | Forward1) 1 – 5 km/h Forward2) 2 – 10 km/h Forward3) 3- 18 km/h Forward4) 4- 32 km/h Backward1) 1- 5 km/h Backward2) 2- 10 km/h Backward3) 3- 18 km/h Backward4) 4- 32 km/h | |
6 | Tyre model | 16.9-28 | |
Hydraulic system | |||
1 | Working pump displacement | 3x25ml/r | |
2 | Working pump pressure | 20Mpa | |
3 | Diverter model | BZZ5-250 | |
Hydraulic hammer | |||
1 | Rod diameter | 68-70mm | |
2 | Working pressure | 11-14Mpa | |
3 | Impact frequency | 500-900 | |
4 | Flow scope | 25-45 L/min | |
5 | Kinetic energy | 49KN | |
Oil capacity | |||
Hydraulic oil tank | 125L | ||
Fuel tank | 125L | ||
Gearbox | Youtop | ||
Bridge | Youtop | ||
Hydraulic pump | Jinan Quancheng | ||
Steering gear and priority valve | Eaton | ||
Excavate the pipeline of crushing hammer after crushing hammer | Whole set | ||
Slide block | Hydraulic sliding | ||
Wheels and Specifications | 6.9.-28 Four-wheel steering dimension 16.9-28 | ||
