| Machine Rating | Dimensions | ||
| ITEMS | SPECIFICATIONS | ITEMS | SPECIFICATIONS |
| Engine Brand | KOOP/BRIGGS/RATO | Height at Maximum Extension/mm | 2450 |
| Rated Power/HP | 12-13.5HP | Height To the the bucket pin /mm | 1870 |
| Rated Speed/rpm | 3000 | Vehicle height | 1300 |
| Number of cylinders | 1 | Maximum Height as Lay the bucket flat/mm | 1810 |
| Air intake way | Naturally Aspirated | Total length without appendages/mm | 1450 |
| Displacement/cc | 420 | Length With standard bucket /mm | 2100 |
| Emissions Standards | EUR 5-EPA | Maximum height unloading Angle | 34° |
| Rated Operating Capacity/Kg | 200 | Dumping Height/mm | 1510 |
| Maximum Operating Capacity/Kg | 300 | Discharge Distance/mm | 450 |
| Maximum Breakout Force/KN | 3.5 | The flip Angle of the bucket on the ground | 27° |
| Bucket Capacity/m3 | 0.12 | Bucket flip Angle at highest Pos. | 114° |
| Driving Speed/ km/h | 0-6 | Wheel Base/mm | 850 |
| Total Cycling Time/s | 9 | Ground Clearance/mm | 150 |
| System Operating Pressure /bar | 17-21 | Tail Length/mm | 280 |
| Fuel Tank Capcity/L | 5 | Wheel base (standard tire) /mm | 720 |
| Operating Weight/Kg | 900 | Vehicle width (standard tire) /mm | 880 |
| Track | Bucket width/mm | 1000 | |
