Model | YT-R30 |
Bucket capacity | 1.5m³ |
Rated load | 3000kg |
weight of the whole machine | 2350kg |
Maximum traction force | 45KN |
Maximum gradeability | 21° |
Maximum turning radius (outside of bucket) | 4850mm |
Maximum turning radius (outside of tire) | 4375mm |
Wheel base | 1430mm |
Standard Model Dimensions LxWxH | 4220x1750x2670mm |
engine | |
Model | Weifang 490 |
Type | In-line, vertical, water-cooled, four-cylinder engine |
Rated power | 42KW |
Maximum torque | 270 (N.M) |
Transmission system | |
clutch | dry friction |
Gears | 4F+2R |
Top speed | 24km/h |
steering system | |
Type | Fully hydraulic hinged frame, load sensing |
Steering angle (left and right) | 30° left and right |
Working hydraulic system | |
Working hydraulic system pressure | 160 (kgf/c m²) |
Braking System | |
service brake | oil brake |
Parking | emergency braking |
tire | |
Size 20.5/70-16 | Size 20.5/70-16 |
fuel capacity | |
Fuel tank capacity | 60L |
Hydraulic system capacity | 60L |
